SPECIFICATIONS
PROCESSOR
• AMD APU
• CPU: Zen 2 4c/8t, 2.4-3.5GHz (up to 448 GFlops FP32)
• GPU: 8 RDNA 2 CUs, 1.0-1.6GHz (up to 1.6 TFlops FP32)
• APU Power: 4-15W
RAM: 16 GB LPDDR5 on-board RAM (5500 MT/s quad 32-bit channels)
Storage:
• 64 GB eMMC (PCIe Gen 2 x1)
• 256 GB NVMe SSD (PCIe Gen 3 x4 or PCIe Gen 3 x2*)
• 512 GB high-speed NVMe SSD (PCIe Gen 3 x4 or PCIe Gen 3 x2*)
All models use socketed 2230 m.2 modules (not intended for end-user replacement)
All models include high-speed microSD card slot
*Some 256GB and 512GB models ship with a PCIe Gen 3 x2 SSD. In our testing, we did not see any impact to gaming performance between x2 and x4.
SOFTWARE
Operating System: SteamOS 3.0 (Arch-based)
Desktop: KDE Plasma
CONTROLS AND INPUT
Gamepad Controls
• A B X Y buttons
• D-pad
• L & R analog triggers
• L & R bumpers
• View & Menu buttons
• 4 x assignable grip buttons
Thumbsticks: 2 x full-size analog sticks with capacitive touch
Haptics: HD haptics
Trackpads:
• 2 x 32.5mm square trackpads with haptic feedback
• 55% better latency compared to Steam Controller
• Pressure-sensitivity for configurable click strength
Gyro: 6-Axis IMU
DISPLAY
• Resolution: 1280 x 800px (16:10 aspect ratio)
• Type: Optically bonded IPS LCD for enhanced readability
• Display Size: 7" diagonal
• Brightness: 400 nits typical
• Refresh Rate: 60Hz
• Touch enabled: Yes
• Sensors: Ambient light sensor
CONNECTIVITY
• Bluetooth: Bluetooth 5.0 (support for controllers, accessories and audio)
• Wi-Fi: Dual-band Wi-Fi radio, 2.4GHz and 5GHz, 2 x 2 MIMO, IEEE 802.11a/b/g/n/ac
AUDIO
Channels: Stereo with embedded DSP for an immersive listening experience
Microphones: Dual microphone array
Headphone/mic jack: 3.5mm stereo headphone / headset jack
Digital: Multichannel audio via DisplayPort over USB-C, standard USB-C, or Bluetooth 5.0
POWER
Input: 45W USB Type-C PD3.0 power supply
Battery: 40Whr battery. 2 - 8 hours of gameplay
EXPANSION
microSD: UHS-I supports SD, SDXC and SDHC
External connectivity for controllers & displays: USB-C with DisplayPort 1.4 Alt-mode support; up to 8K @60Hz or 4K @120Hz, USB 3.2 Gen 2
WARRANTY
• 1 year KS Warranty
