General

    Dimensions
    Osmo Mobile 7P
    Unfolded: 288×107×96 mm (L×W×H)
    Folded: 190×95×46 mm (L×W×H)

    Osmo Mobile 7
    Unfolded: 278×107×93 mm (L×W×H)
    Folded: 179×95×39 mm (L×W×H)

    Weight
    Osmo Mobile 7P
    Gimbal + Built-in Tripod + Magnetic Phone Clamp + Multifunctional Module: Approx. 368 g

    Osmo Mobile 7
    Gimbal + Built-in Tripod + Magnetic Phone Clamp: Approx. 300 g

    Data was collected in a controlled environment. Actual experience may vary.

    Extension Rod
    Osmo Mobile 7P
    Built-in Extension Rod
    Max Extension Length: 215 mm

    Osmo Mobile 7
    No Built-in Extension Rod

    Compatible Phone Weight
    170-300 g

    Compatible Phone Thickness
    6.9-10 mm

    Compatible Phone Width
    67-84 mm

    Bottom Port
    1/4" Screw Hole

Battery

    Type
    Li-Po 1S

    Capacity
    3350 mAh

    Energy
    12.06 Wh

    Charging Temperature
    5° to 40° C (41° to 104° F)

    Operating Temperature
    0° to 40° C (32° to 104° F)

    Operating Time
    Osmo Mobile 7P
    Approx. 10 hours
    (Measured with the gimbal balanced in a level and stationary state without additional accessories)

    Osmo Mobile 7
    Approx. 10 hours
    (Measured with the gimbal balanced in a level and stationary state without additional accessories)

    With the Multifunctional Module's intelligent tracking feature enabled and the fill light off, the operating time is approximately 5 hours. When the intelligent tracking feature is on and the fill light is set to maximum brightness, the operating time is approximately 4 hours.Using the gimbal to charge your smartphone will shorten the gimbal's operating time.

    Charging Time
    Approx. 2.5 hours
    (Measured with a 10W USB-C charger)

    Gimbal Charging Port
    USB-C

    Phone Charging
    Supported

Gimbal

    Controllable Range
    Pan: -99° to 210°
    Roll: -67° to 245°
    Tilt: -20° to 40°

    Mechanical Range
    Pan: -109° to 222°
    Roll: -77° to 255°
    Tilt: -224° to 100°

    Max Control Speed
    120°/s

Wireless Mode

    Model
    Bluetooth 5.3

Software

    App
    DJI Mimo

Tripod

    Dimensions
    Built-in Tripod
    Length: 67 mm

Multifunctional Module

    Compatibility
    Osmo Mobile 7P
    Supported (standard)

    Osmo Mobile 7
    Supported (optional)

    GFSK
    2 Mbps

    GFSK Transmitter Power (EIRP)
    < 16 dBm

    GFSK Operating Frequency
    2.4000-2.4835 GHz

    Bluetooth Protocol
    Bluetooth 5.3

    Bluetooth Transmitter Power (EIRP)
    < 16 dBm

    Bluetooth Operating Frequency
    2.4000-2.4835 GHz

    Fill Light Illuminance
    40 lux

    This represents the maximum brightness measured at a distance of 0.6 meters from the subject and should be used for reference only.

    Fill Light Color Temperature
    2500-6000 K

1 year DJI warranty
