Specs
Peripheral

    Accessory Port
    NATO Port
    1/4"-20 Mounting Hole
    RSS Camera Control Port (USB-C)
    Pogo Pin (compatible with the DJI RS Intelligent Tracking Module)

    Battery
    Model: BHX724-3100-7.2
    Type: LiPo 2S
    Capacity: 3100 mAh
    Energy: 22.32 Wh
    Max Runtime: 13 hours (stationary) *
    Charging Specification: 9 V/2.5 A
    Charging Time: Approx. 1 hour and 50 minutes **
    Suggested Charging Temperature: 5° to 40° C (41° to 104° F)

    * Measured with the equipment in a level and stationary state and the gimbal balanced. When the gimbal is in motion, the operating time will be reduced.
    ** Tested in a 25° C (77° F) environment while using a 30W charger.

    Connections
    Bluetooth 5.1
    USB-C Charging Port

    Ronin App Requirements
    iOS 14.0 or above
    Android 9.0 or above

    Languages Supported by the Touchscreen
    English, Simplified Chinese, Traditional Chinese, German, French, Korean, Japanese, Spanish, Portuguese (Brazil), Russian, Thai

Working Performance

    Tested Payload
    0.4-2 kg (0.88-4.4 lbs)

    Maximum Controlled Rotation Speed
    Pan: 360°/s
    Tilt: 360°/s
    Roll: 360°/s

    Mechanical Range
    Pan Axis: 360° continuous rotation
    Roll Axis: -95° to +235°
    Tilt Axis: -110° to +210°

    Axis Locks
    Auto

    Vertical Shooting
    Supported

Mechanical & Electrical Properties

    Operating Frequency
    2.4000-2.4835 GHz

    Bluetooth Transmitter Power
    < 4 dBm

    Operating Temperature
    -10° to 45° C (14° to 113° F)

    Weight
    Gimbal: Approx. 890 g (2 lbs) (including the Quick-Release Plate and excluding the tripod)
    Extended Grip/Tripod: Approx. 140 g (0.3 lbs)

    Dimensions
    Folded: 236×64×316 mm (L×W×H, excluding the tripod and the Quick-Release Plate)
    Unfolded: 175×182×338 mm (L×W×H, excluding camera, tripod, and the Quick-Release Plate)

Inclusion:
- Gimbal
- RS Intelligent Tracking Module
- Quick Release Plate
- RS 4 Mini Tripod
- L-shaped multi-camera control cable (USB-C, 30cm)
- USB-C Charging Cable (40cm)
- Screw kit
- RS 4 Mini briefcase handle
